Chapter 11: Reference Section 245
MIDI SPECIFICATION
• Patchcord Destinations
The MIDI patchcord destination numbers are unique across all Proteus
type products. Note-on and realtime numbers are shared. The chart
shows whether a cord is available to note-on (NO) realtime (RT) or
both. The patchcord destinations available to Morpheus are as follows:
MIDI Description NO/RT
Value Availability
0 Off RT/NO
1 Pitch RT/NO
2 PitchP RT/NO
3 PitchS RT/NO
4 Volume RT/NO
5 VolumeP RT/NO
6 VolumeS RT/NO
7 Attack RT/NO
8 AttackP RT/NO
9 AttackS RT/NO
10 Decay RT/NO
11 DecayP RT/NO
12 DecayS RT/NO
13 Release RT/NO
14 RelP RT/NO
15 RelS RT/NO
16 XFade RT/NO
17 Lfo1Amt RT/NO
18 Lfo1Rt RT/NO
19 Lfo2Amt RT/NO
20 Lfo2Rt RT/NO
21 AuxAmt RT/NO
22 AuxAtt RT/NO
23 AuxDec RT/NO
24 AuxRel RT/NO
25 Start NO
26 StartP NO
27 StartS NO
28 Pan RT/NO
29 PanP RT/NO
30 PanS RT/NO
31 Tone NO
