Morpheus Operation Manual32
MIDIMAP MENU
The Output Mix allows you to selectively route the program through
one of the effects processors or direct it to a pair of output jacks (for
each of the 16 MIDI channels). An additional selection called Preset or
“P”, allows the selection to be made in the preset (Mix Output). Thus
effects and outputs can be selected according to MIDI channel or by
preset.
Position the cursor under the channel number and use the data entry
control to change the MIDI channel. Position the cursor under the
volume, pan or mix and use the data entry control to change the
value. The volume and pan values are the same ones shown in the
main screen.
The diagram below shows the function of Output Mix Select.
The Output Mix Select (for each MIDI channel) selects which bus in the Output
Section will be used.
•• Please note that the Sub
Output is an “Effects Only”
utput.
