Eaton MVX9000 - Table 5-7: RTU Mode

Group 90 — Communications
MVX9000 User Manual 5-71
Descriptions of
Parameter Settings
Table 5-7: RTU mode
Command message Response message
ADR 01H ADR 01H
CMD 03H CMD 03H
Starting data address 21H Number of data
(Count by byte)
04H
02H
Number of data
(count by word)
00H Content of data address
2102H
17H
02H 70H
CRC CHK Low 6FH Content of data address
2103H
00H
CRC CHK High F7H 00H
CRC CHK Low FEH
CRC CHK High 5CH
