EMI Filter Cross-Reference
C-6 MVX9000 User Manual
Accessories
EMI Filters
Figure C-1: EMI Filter (K13-000034-0111) Used on
1/2 – 2 hp/230V Single-Phase Models — Approximate Dimensions in Inches (mm)
Figure C-2: EMI Filter (K13-000034-0112) Used on
3 hp/230V Single-Phase Models — Approximate Dimensions in Inches (mm)
1.77±.08
(45.0±2.0)
D
C
3.94±.04
(100.0±1.0)
Power-In
7.80±.04
(198.0±1.0)
E
F
7.87±.39
(200.0±10.0)
M4 x 0.7
Typ. 3 Places
A
8.66±.08
(220.0±2.0)
B
5.12±.08
(130.0±2.0)
1015 AWG
14 Y/G
1015 AWG
14 Blue
1015 AWG
14 Brown
N/L2
L/L1
1015 AWG
12 G/Y
1015 AWG
12 Blue
1015 AWG
12 Black
N/L2
L/L1
1.97±.08
(50.0±2.0)
C
D
4.80±.04
(122.0±1.0)
Power-In
7.21±.04
(284.0±1.0)
.39 (10.0)
9.84±.39
(250.0±10.0)
F
.18 (4.5) Radius
.12 (3.0) Radius
M5 x 0.8
Typ. 4 Places
.31 (8.0) Dia.
Typ. 4 Places
7.21±.04
(284.0±1.0)
A
12.05±.08
(306.0±2.0)
6.02±.08
(153.0±2.0)
E
H
.98±.04
(25.0±1.0)
G
B
