MVX9000 Parameter Listing
B-2 MVX9000 User Manual
Parameter Tables
MVX9000 Parameter Listing
Table B-1: 20 — BASIC GROUPING (Quick Start)
Modbus Groups Page # Description Range Default
User
Settings
0000H 20.01
50.05
5-5 Motor Nameplate
Frequency
10.0 to 400.0 Hz 60.0
0001H 20.02
50.06
5-5 Motor Nameplate
Voltage
115/230V drives: 1.0 to 255V 230
460V drives: 1.0 to 510V 460
575V drives: 1.0 to 637V 575
0002H 20.03
50.01
5-5 Source of Master
Frequency
00: Master frequency
determined by digital keypad
up/down
01
01: Master frequency
determined by keypad
potentiometer
02: Master frequency
determined by 0 to +10V
input on AI terminal
03: Master frequency
determined by 4 to 20 mA
input on AI terminal
04: Master frequency
determined by RS-485
communication interface
0003H 20.04
50.02
5-5 Source of Operation
command
00: Operation commands
determined by digital keypad
00
01: Operation commands
determined by external
control terminals, keypad
STOP is effective
02: Operation commands
determined by external
control terminals, keypad
STOP is ineffective
03: Operation commands
determined by RS-485
interface, keypad STOP is
effective
04: Operation commands
determined by RS-485
interface, keypad STOP is
ineffective
0004H 20.05
60.01
5-6 Motor Rated Current 30 to 120% FLA
0005H 20.06
50.09
5-6 Minimum Output
Frequency
0.0 to 20.0 Hz 1.5
0006H 20.07
50.04
5-6 Maximum Output
Frequency
50.0 to 400.0 Hz 60.0
0007H 20.08
50.12
5-6 Acceleration Time 1 0.01 to 600.0 sec 10.0
0008H 20.09
50.13
5-6 Deceleration Time 1 0.01 to 600.0 sec 10.0
