Wiring
MVX9000 User Manual C-3
Accessories
Wiring
Table C-2: Wiring Table
Catalog Number
Voltage,
Horsepower
Max. Current
(A)
(Input/
Output)
Wire Gauge
(AWG)
Torque
Rating
(kgf-cm)
MVXF25A0-1 (1-phase) 115V AC, 1/4 hp 6/1.6 12 – 14 14
MVXF50A0-1 (1-phase) 115V AC, 1/2 hp 9/2.5 12 – 14
MVX001A0-1 (1-phase) 115V AC, 1 hp 16/4.2 12
MVXF50A0-2 (1-phase) 240V AC, 1/2 hp 6.3/2.5 12-14 14
MVXF50A0-2 (3-phase) 240V AC, 1/2 hp 3.2/2.5 12-14
MVX001A0-2 (1-phase) 240V AC, 1 hp 11.5/5 12-14
MVX001A0-2 (3-phase) 240V AC, 1 hp 6.3/5 12-14
MVX002A0-2 (1-phase) 240V AC, 2 hp 15.7/7 12
MVX002A0-2 (3-phase) 240V AC, 2 hp 9/7 12-14
MVX003A0-2 (1-phase) 240V AC, 3 hp 27/10 8 15
MVX003A0-2 (3-phase) 240V AC, 3 hp 15/10 8-12
MVX005A0-2 240V AC, 5 hp 19.6/17 8-10
MVX007A0-2 240V AC, 7-1/2 hp 28/25 8
MVX001A0-4 480V AC, 1 hp 4.2/3 12-14 14
MVX002A0-4 480V AC, 2 hp 5.6/4 12-14
MVX003A0-4 480V AC, 3 hp 6/5 12-14
MVX005A0-4 480V AC, 5 hp 8.5/8.2 8-14 15
MVX007A0-4 480V AC, 7-1/2 hp 14/13 8-12
MVX010A0-4 480V AC, 10 hp 23/18 8-10
MVX001A0-5 575V AC, 1 hp 1.7/2.4 12 – 14 14
MVX002A0-5 575V AC, 2 hp 3.0/4.2
MVX003A0-5 575V AC, 3 hp 4.2/5.9
MVX005A0-5 575V AC, 5 hp 6.6/7.0 8 – 14 15
MVX007A0-5 575V AC, 7-1/2 hp 9.9/10.5
MVX010A0-5 575V AC, 10 hp 12.2/12.9 8 – 12
