EMI Filter Cross-Reference
MVX9000 User Manual C-5
Accessories
EMI Filter Cross-Reference
Table C-4: EMI Filter Cross-Reference
If users want to operate the AC motor drive in coordination with the EMI filters
manufactured by Eaton, refer to the above table for the appropriate I/O terminals
of the applicable filters.
Model of AC Drive hp/Voltage EMI Filter
MVXF50A0-2 1/2 hp, 230V AC, Single-phase K13-000034-0111
MVX001A0-2 1 hp, 230V AC, Single-phase K13-000034-0111
MVX002A0-2 2 hp, 230V AC, Single-phase K13-000034-0111
MVX003A0-2 3 hp, 230V AC, Single-phase K13-000034-0112
MVXF50A0-2 1/2 hp, 230V AC, Three-phase K13-000034-0113
MVX001A0-2 1 hp, 230V AC, Three-phase K13-000034-0113
MVX002A0-2 2 hp, 230V AC, Three-phase K13-000034-0113
MVX003A0-2 3 hp, 230V AC, Three-phase K13-000034-0113
MVX001A0-4 1 hp, 460V AC, Single-phase K13-000034-0114
MVX002A0-4 2 hp, 460V AC, Single-phase K13-000034-0114
MVX003A0-4 3 hp, 460V AC, Single-phase K13-000034-0114
MVX005A0-2 5 hp, 230V AC, Three-phase K13-000034-0115
MVX007A0-2 7-1/2 hp, 230V AC, Three-phase K13-000034-0115
MVX005A0-4 5 hp, 460V AC, Three-phase K13-000034-0116
MVX007A0-4 7-1/2 hp, 460V AC, Three-phase K13-000034-0116
MVX010A0-4 10 hp, 460V AC, Three-phase K13-000034-0117
The filter will cause a high leakage circuit. Grounding is required.
