Table 43 Water cooler
Water Cooler
Item Number
nEXT85 water cooler B8G200833
13.3 Flange heater
A ange heater increases the degassing of the pump to enable it to achieve lower
pressures. It can also be used to protect the pump from condensaon of contaminants.
The ange heaters are available in 110 V and 240 V versions.
Note:
Use the ange heater only with CF variants.
Table 44
Flange heater
Water Cooler
Item Number
nEXT85 (110 V) ange heater B8G200823
nEXT85 (240 V) ange heater B8G200824
13.4 TAV5 vent valve
A 24 V d.c. TAV5 solenoid-operated vent valve opons are available for system venng.
These are normally open (N/O) or normally closed (N/C).
The valves are available with either a wired connector which connects directly to the
auxiliary port on the controller or as a bare wire opon.
All vent valves have an 0.5 mm diameter orice and are applicable to vent small vacuum
systems of less than 5 litres.
The vent valves are pre-wired to Vent Opon 1 and the default is set to fully vent at 50%
(opon 0). The solenoid valve is installed in place of the manual valve, or can be installed
with an adaptor (supplied with the valve). Use the valves with an applicable NW10
anged port on the vacuum system. The vent port adaptor lets the vent port or the
purge port to be used with an applicable NW10 ng.
Table 45 TAV vent valve and vent port adaptor
Product
Item Number
nEXT85 TAV5 kit N/C connector ed
(0.3 m)
B8G200835
nEXT85 TAV5 kit N/C bare wire (3 m) B58066040
nEXT85 TAV5 kit N/O connector ed
(0.3 m)
B8G200834
nEXT85 TAV5 kit N/O bare wire (3 m) B58066010
13.5 VRX vent restrictor
Use a VRX installed orice vent restrictor to restrict the ow of vent gas into the pump.
Page 102
B8G000880_D - Accessories
