Edwards nEXT nEXT85 - Monitor Temperature Readings; Monitor Link Parameter Readings; Monitor Measured Motor Speed

Reply * c 8 5 2 sp r cr
6.4.5 Monitor temperature readings
It is possible to monitor the following parameters:
▪ temperatures of the pump motor
▪ rotor
▪ internal electronics of the pump.
Send the query that follows:
Command ? v 8 6 5 sp cr
The reply is as follows:
Reply = v 8 6 5 sp d d d ; d d d ; d d d cr
Here:
▪
rst number is the motor temperature
▪ second number is the motor controller temperature
▪
third number is the rotor temperature, all measured in °C.
6.4.6 Monitor link parameter readings
The parameters that follows can be monitored:
▪ internal voltage
▪ current and motor power of the pump.
Send the query that follows:
Command ? v 8 6 0 cr
The reply is as follows:
Reply = v 8 6 0 sp d d d ; d d d ; d d d d d cr
Here:
▪
rst number shows the link voltage (measured in 0.1 Volts - i.e. divide the number
by 10 to get the answer in Volts)
▪
second number shows the link current (measured in 0.1 Amps)
▪
third number shows the link power (measured in 0.1 Was).
6.4.7 Monitor measured motor speed
The measured rotaonal speed of the motor in the pump can be monitored.
Send the query that follows:
Command ? v 8 5 2 cr
The reply is follows (where rst returned number shows the motor rotaonal speed in
revoluons per second (Hz)):
