Edwards nEXT nEXT85 - Installation; Unpack and Inspect

4. Installaon
4.1 Unpack and inspect
The pump is supplied in a cardboard box and the liing equipment is not necessary.
WARNING: HEAVY OBJECT
Risk of injury or damage to the equipment. Take necessary precauon when you li
and move the pump to prevent injury. Obey the manual handling guidelines.
Do not use the controller cable as a liing device. Do not use the cable to li or
support the pump.
CAUTION: IMPACT ON ENVIRONMENT
Risk of damage to environment. When you install and remove of the pump, obey the
local legislaon about the impact of the pump on the environment.
1.
Store the pump in its sealed bag unl it is installed.
2.
Be careful when you unpack the pump to prevent the excessive shocks. The
excessive shocks can damage the bearings and decrease the life of the pump. The
pump is supplied with sealed inlets and outlets to prevent the entry of dust and
vapour.
3. Do not remove the seals unl the pump is installed on the vacuum system.
4.
Open the cardboard box from the top.
5. Open the box lid.
6. Remove the foam and open the bag.
7. Keep all the packing materials for use in inspecon and in case the pump is
returned for service.
8.
If the pump is damaged, nofy your supplier and the carrier immediately. Give the
supplier and the carrier the informaon that follows:
▪ part number of the pump
▪ serial number of the pump
▪
order number
▪
supplier's invoice number
9.
1. Do not use the pump if the pump is damaged.
10.
Check that the package has the items given in Table: Checklist of items on page 35.
If the items are missing, nofy the supplier in wring in three days.
11.
If the pump is not to be used immediately, store the pump in condions as given in
Storage on page 95.
Table 17
Checklist of items
Quanty Descripon
Check (
ü)
1 nEXT Turbomolecular Vacuum Pump ❏
Page 35
B8G000880_D - Installaon
