13.12 Auxiliary 'Y' cable adaptor
The auxiliary 'Y' cable adaptor enables:
a TAV5 vent valve and a cooling fan or
two cooling fans or
2 TAV5 vent valves to be operated at the same me.
The two sockets of the Y-cable are wired in parallel so an applicable connector can be
used in the same way as the auxiliary connector on the pump.
Table 52
Auxiliary extension cable
Item
Item Number
nEXT85 auxiliary ‘Y’ cable adaptor B8G200837
13.13 Base mounng adaptor
A base mounted adaptor is available to enable the pump to be mounted in the same
posion as an EXT75DX pump.
Table 53
Base mounng adaptor
Item
Item Number
nEXT85 base mounng adaptor B8G200838
Page 105
B8G000880_D - Accessories
