135Installation and Service Guide: Color Controller E-85
Servicing the System with Furniture
2 Open the back door of the NX Station and remove all the cables from the connector panel of the E-85.
3 Pull the server tray of the NX Station out of the stand.
To replace the E-85 in the furniture
1 Make sure that all the chassis panels are attached.
2 Lift the E-85 and place it on the server tray.
3 Slide the tray into the stand.
4 Reconnect all the cables.
To avoid injury, do not lift the E-85 without assistance. The E-85 weighs approximately 22kg. At least two persons
are required to move the device.
