23Installation and Service Guide: Color Controller E-85
Installing hardware
Starting the E-85 for the first time
This section describes how to start the E-85 for the first time after connecting the cables.
To start the E-85
1 Make sure that the power switch on the back of the E-85 is in the ON (|) position.
Figure 7: E-85 power switch
2 Power on the E-85 using the power button ( ) on the front panel.
Press once and release the button to power on the system. The power supply automatically senses the correct voltage.
Figure 8: E-85 power button
3 Check the activities on the Fiery QuickTouch.
The power supply automatically senses the correct voltage. Allow startup to proceed without interruption. Do not press
any buttons while the system is starting.
1Power switch
1 Power button
1
1
