83Installation and Service Guide: Color Controller E-85
Replacing parts
Restoring and verifying functionality after service
Complete your inspection and service by reassembling and verifying the E-85.
To reassemble and verify the E-85
1 Reseat all boards, cables, connectors, and other parts loosened or removed during service.
When routing cables in the E-85 make sure that:
• Covers are securely installed after routing cables.
• Cables are not looped around internal circuit boards, or components (such as capacitors and resistors).
• Cable routing does not interfere with the operation of internal components.
• Cables do not lie on or against any internal heating element.
• Cables do not interfere with removing or replacing components.
• Cables do not interfere with opening or closing E-85 panels.
• Cables are not tangled.
• Cable slack is secured with tie wraps.
2 Restore the system to the upright position.
3 Replace any panels that you removed earlier, as described in “Opening the E-85” on page 48.
4 Reinstall the E-85 in the furniture, as described in “To replace the E-85 in the furniture” on page 135.
This replacement procedure includes reattaching the monitor assembly and the left panel.
5 If you installed a new hard disk drive, install system software (see page 97).
Replacement hard disk drives are not shipped with pre-installed system software.
6 If you replaced the motherboard with a new motherboard, make sure that the new motherboard solves the problem that
you are troubleshooting (see page 62), and then transfer options to the new motherboard (see page 63).
7 Make sure to configure the date and time in Setup.
For more information, see Configuration and Setup, which is part of the user documentation set.
8 Before you leave the customer site, verify the E-85 operation.
Verify the E-85 operation
1 Make sure you reassemble the E-85 (see page 83). For cable connections see page 46 and page 47.
2 Connect the monitor, keyboard, mouse, and dongles to the E-85 (see page 20).
3 Connect power to the E-85 (see page 20).
Warning: Do not lift the E-85 without assistance. Follow standard ESD precautions when handling internal
components (see page 11).
