67Installation and Service Guide: Color Controller E-85
Replacing parts
• When installing more than eight DIMMs, use the following table for the available slots.
Table 3: Available DIMM slots
To replace a DIMM
1 Shut down the E-85, remove all cables from the back, and open the system (see page 48).
To access the DIMMs, you must remove the left panel.
Number of
DIMMs
4 5 6 7 8 10 12 14 16
Set 0 - Socket A0ooooooooo
Set 0 - Socket A1 oooo
Set 0 - Socket B0ooooooooo
Set 0 - Socket B1 oooo
Set 0 - Socket C0 oooooooo
Set 0 - Socket C1 ooo
Set 0 - Socket D0 oooooo
Set 0 - Socket D1 ooo
Set 1 - Socket A0ooooooooo
Set 1 - Socket A1 o o
Set 1 - Socket B0ooooooooo
Set 1 - Socket B1 o o
Set 1 - Socket C0 ooooooo
Set 1 - Socket C1 o
Set 1 - Socket D0 ooooo
Set 1 - Socket D1 o
