Resistance welder MULTISPOT MI-100control
Specifications
85
9 Specifications
9.1 Dimensions and weights
Item Value Unit
Height 1100 /43 mm / in
Width 690 /27 mm / in
Depth 600 /23.6 mm / in
Weight (w/o accessories) 100 / 220 kg / lb
9.2 Power requirements
Power supply
Item Value Value Value Unit
Mains voltage 480 / 3 ~
50 / 60
400 / 3 ~
50 / 60
230 / 3 ~
50 / 60
V / Ph
Hz
Admissible voltage range 440 – 500 380 – 415 208 – 240 V (AC)
Power cord 6
AWG 10
6
AWG 10
16
AWG 6
mm
2
/ 10 m
33 ft
Mains fuse, min. 32 32 63 A slow-blow
Installed power 42 42 42 kVA
Rated output at 50% duty cycle 60 60 60 kVA
No load voltage, max. 23 23 23 V (DC)
weld current, regulated, max. 12000 12000 12000 A (DC)
Enclosure IP21
Compressed-air supply
Item Value Unit
Operating pressure, min. – max. 6 – 10
87 – 145
bar
Psi
Quality clean, dry, free of oil
Cooling water pump
Item Value Unit
Operaiting air pressure 6 / 87 bar / Psi
Flow rate 2.5 /0.66 l/min / gal
