Resistance welder MULTISPOT MI-100control
Troubleshooting
74
7 Troubleshooting
7.1 Health and safety during troubleshooting
People with insufficient skills may suffer injuries!
If you carry out troubleshooting and repairs yourself, you may encounter certain risks
and hazards that may entail severe injuries.
Therefore:
Do not open the welder. Do not modify the welder. Do not try to carry out repairs
yourself.
For any and all troubleshooting measures not explicitly mentioned and / or
described in this manual, you should call service personnel and / or contact the
manufacturer.
Be sure to adhere strictly to the hierarchy of responsibilities defined in the table.
When you're in doubt: do contact service personnel / manufacturer.
If damage does occur: minimise, contain and avert consequential damage.
NOTE!
In the event that problems occur more frequently due to above-average workloads,
you must adapt the inspection and maintenance intervals accordingly.
7.2 Error messages and troubleshooting tables
7.2.1 Problems displayed on the control panel
Message What’s the problem What should be done?
Who should
do it?
Welding job has been
successfully re-adjusted
There has been some problem, and
the welder has re-adjusted the weld
parameters accordingly.
Nothing, the control unit has
solved the problem.
---——
Welding not sufficient. –
Urgently repeat. – Check
contacts and / or mains.
Sheets may have been insufficiently
prepared.
Hunt down the problem by
elimination and solve it.
Operator
Power supply too weak.
Problem with pliers and / or caps.
Problem with line-up.
Automatic tool recognition
not possible. Please select
a tool.
The ID code of the tool installed is
unknown or defective.
Check the tool. Replace, if
necessary. Set the tool
manually.
( “6.4.4”).
Operator
At least 1 mains phase is
missing. – Please check
power supply.
A mains phase is missing. Check the supply from the
mains of the operating
company.
Skilled
electrician
A mains fuse has been triggered.
An internal fuse has been triggered.
