ELNA eXpressive 970 - Sub Control Panel; RCS Unit (Optional for some Models)

6
CAUTION:
Do not press the LCD touch panel with hard or sharp
pointed objects like pencils, screwdrivers or the like.
Press the LCD touch panel and buttons gently.
Rough or forceful pressing may damage the unit.
w
e
r
t
y
u
q
w
e
r
t
o
i
!2
y
!1
!0
q
Sub control panel
q
MODE button
w
Trace button
e
Arrow buttons
r
ENTER button
t
LCD brightness adjusting dial
y
LCD display
RCS unit (optional for some models)
q
RCS unit
w
START/STOP button
e
Auto thread cutter button
r
Trace button
t
Jog buttons
y
Carriage return button
u
Stitch back button
i
Stitch forward button
o
Bobbin winder button
!0
Bobbin winder indicator
!1
USB port
!2
LCD touch panel
* The RCS unit is for 7-needle embroidery machine only
and cannot be used for other models.
