ELNA eXpressive 970 - Replacing the Needle

32
Replacing the needle
WARNING:
Always make sure to turn the power off before
replacing the needle.
z Loosen the needle clamp screw with the small
screwdriver included in the standard accessory.
Pull the needle out from the needle clamp.
q Small screwdriver
w Needle clamp screw
Checking the needle
Check the needle regularly and replace it with new one if
it is bent or dull.
To check the straightness of the needle, place it onto
something at. The gap between the needle shaft and
the at surface should be consistent.
r Gap
CAUTION:
Do not use the bent or blunt needle.
The bent needle can cause it to break.
r
w
q
q
w
e
x
z
x Insert a new needle into the needle clamp with the
long groove facing you.
Push the needle up as far as it will go and tighten the
needle clamp screw securely with the screwdriver.
q Small screwdriver
w Needle clamp screw
e Long groove
