ELNA eXpressive 970 - Removing the Bobbin Case; Removing the Bobbin

16
z
x
q
w
Removing the bobbin
Release the latch and take out the bobbin.
q Latch
w Bobbin
q
w
e
r
Removing the bobbin case
CAUTION:
Turn the power switch off before removing the bobbin
case.
z Open the hook cover toward you.
q Hook cover
x Hold and open the latch of the bobbin case.
Take the bobbin case out from the machine.
w Bobbin case
e Latch
CAUTION:
Do not force to pull the thread keeper when you
remove the bobbin case.
r Thread keeper
