11
x Hold the hoop supporter with both hands and place it
under the carriage plate by inserting the necks of both
thumbscrews into the slots in the carriage plate.
e Slot in the carriage plate
q
w
e
w
w
c Tighten the thumbscrews with the screwdriver to
secure the hoop supporter.
* When carrying the machine, remove the hoop supporter
from the machine.
Installing the Hoop Supporter
CAUTION:
Turn the power switch off before installing the hoop
supporter.
z Loosen the two thumbscrews on the hoop supporter.
q Hoop supporter
w Thumbscrew
c
x
z
