eMachines E644G - DC-IN Cable Removal

Machine Maintenance Procedures 3-41
DC-IN Cable Removal 0
Prerequisite:
Mainboard Removal
1. Find DC-IN (Direct Current Input) cable (A) in lower cover. (Figure 3-38)
Figure 3-38. DC-IN Cable Location
2. Remove DC-IN cable from cable guides (B). (Figure 3-39)
Figure 3-39. DC-IN Cable
3. Remove DC-IN cable from lower cover. (Figure 3-39)
A
B
