5-6 Jumper and Connector Locations
Power Board Jumper and Connector Locations 0
Figure 5-4. Power Board Top
Figure 5-5. Power Board Bottom
Table 5-4. Power Board
Item Description
JP1 Connect to mainboard (w/ FFC)
