Jumper and Connector Locations 5-5
USB Board Jumper and Connector Locations 0
Figure 5-3. USB Board
Table 5-3. USB Board
Item Description
JUSB1 / JUSB2 USB connector
JP1 Connect to mainboard (w/ FFC)
