eMachines E644G - LCD Panel Removal

3-48 Machine Maintenance Procedures
LCD Panel Removal 0
Prerequisite:
LCD Bezel Removal
1. Remove the four (4) securing screws (A) from the LCD panel (B). (Figure 3-46)
Figure 3-46. LCD Panel
2. Remove the LVDS cable (C) from the cable guides. (Figure 3-47)
Figure 3-47. LVDS Cable
3. Lift the LCD panel (B) from LCD cover. (Figure 3-46)
A
A
A
A
B
C
