Machine Maintenance Procedures 3-11
Keyboard FPC (Flexible Printed Circuit) can be damaged if removed while
mainboard connector is locked.
Keyboard Installation 0
1. Put the keyboard face down on the palm rest (C). (Figure 3-6)
2. Connect keyboard FPC (A) to mainboard connector (B). (Figure 3-6)
3. Turn the keyboard over and align the keyboard with the indentation in the upper cover.
4. Press down to secure the latches on the upper cover. (Figure 3-5)
5. Install battery.
