1-16 Hardware Specifications and Configurations
Base View 0
Figure 1-6. Base View
Table 1-6. Base View
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch Releases the battery for removal.
3 Hard disk bay Houses the computer's hard disk (secured
with screws).
Memory compartment Houses the computer's main memory.
4 Battery lock Locks the battery in position.
1
2
3
4
