eMachines E644G - LCD Bezel Removal

Machine Maintenance Procedures 3-43
LCD Bezel Removal 0
Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Remove two screw caps. (Figure 3-40)
2. Remove two (2) screws (A) from the LCD module. (Figure 3-40)
Figure 3-40. LCD Bezel
3. Lift the bottom of the bezel up releasing it from the latches. (Figure 3-41)
Figure 3-41. LCD Bezel
A
