eMachines E644G - DIMM (Dual In-Line Memory Module) Module Removal

Machine Maintenance Procedures 3-15
DIMM (Dual In-line Memory Module) Module Removal 0
Prerequisite:
Base Door Removal
1. Find DIMM (D) in the component bay. (Figure 3-10)
Figure 3-10. Component Location
2. Push DIMM clips (A) outwards. (Figure 3-11)
Figure 3-11. DIMM Modules
A
B C
D
A
B
