Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
d0-07
Stator resistance R1 of
motor
Range: 0.001Ω - 65.535Ω
Factory default:
model defined
d0-08
Leakage inductance L1 of
motor
Range: 0.1mH - 6553.5mH
Factory default:
model defined
d0-09
Rotor resistance R2 of
motor
Range: 0.001Ω - 65.535Ω
Factory default:
model defined
d0-10
Mutual inductance L2 of
motor
Range: 0.1mH - 6553.5mH
Factory default:
model defined
d0-11 No-load current of motor Range: 0.0A - 6553.5A
Factory default:
model defined
d0-12
Flux weakening coeff 1 of
motor
Range: 0.0000 - 1.0000
Factory default:
model defined
d0-13
Flux weakening coeff 2 of
motor
Range: 0.0000 - 1.0000
Factory default:
model defined
d0-14
Flux weakening coeff 3 of
motor
Range: 0.0000 - 1.0000
Factory default:
model defined
The drive needs above-noted paramters to control its matching motor. If the parameters of
motor is known, just write the actual value into d0-07 - d0-14 correspondingly.
After the identification of parameters of motor, above-noted parameters are automatically
updated and saved. Parameters d0-07 - d0-09 are obtained through static identification, and
parameters d0-07 - d0-14 are obtained through rotation identification. If above-noted
parameters are unknown and it is not allowed to perform motor parameter identification, please
input the parameters manually by referring to parameters of like motors.
If motor power rating d0-01 is changed, d0-02 - d0-14 will be automatically restored to
default setting of the standard motor.
d0-22
Parameter identification of
motor
Range: 0 - 2 Factory default: 0
Parameters for controlling the motor performance are automatically obtained through
parameter identification, and the result will be automatically saved upon the completion of
identification.
Be sure to correctly input motor parameters d0-01 - d0-06 before parameter identification.
0: No action
1: Static identification
Static identification applies to the cases where rotating identification cannot be favorably
performed due to the fact that it is impossible to disengage the motor from its load. After
d0-22 is set to 1 and confirmed, press the key RUN to start static identification. d0-22 will be
restored to 0 upon the successful completion of identification. In this way, parameters d0-07 -
d0-09 are obtained.
- 112 -
