Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
F0-23
Maximum FREQ when
opposite to command direction
Range: 0.00Hz - maximum
frequency
Factory default:
50.00Hz
When run command direction is forward, while PID output is reverse, the maximum reverse
frequency will be determined by F0-23.
When run command direction is reverse, while PID output is forward, the maximum
forward frequency will be determined by F0-23.
F0-24
PID computation option
Range: 0 - 1
Factory default: 0
0: No computation in stop status
1: Computation continued in stop status
Group F1 Multi-step Frequency
F1-00
F
requency command
source of multi-step 0
Range: 0 - 8 Factory default: 0
0: Digital setting F1-02
1: Digital setting b0-02 + keypad ∧ / ∨ adjustment
2: Digital setting b0-02 + terminal UP/DOWN adjustment
3:AI
7: Process PID output
8: Communication
At most 8-step of frequency can be set through the combination of "multi-step frequency
terminals 1 - 3" of digital input. Multi-step frequency 2 - 7 are only digital setting while a number
of setting sources can be selected for multi-step frequency 0 - 1. Parameter value of F1-00
determines command source of step 0.
F1-01
Frequency command
source of multi-step 1
Range: 0 - 8 Factory default: 0
0: Digital setting F1-03
1: Digital setting b0-04 + keypad ∧ / ∨ adjustment
2: Digital setting b0-04 + terminal UP/DOWN adjustment
3:AI
7: Process PID output
8: Communication
At most 8-step of frequency can be set through the combination of "multi-step frequency
terminals 1 - 3" of digital input. Multi-step frequency 2 - 7 are only digital setting while a number
of setting sources can be selected for multi-step frequency 0 - 1. Parameter value of F1-01
determines command source of step 1.
- 136 -
