Emotron VSB Instruction Manual Chapter 4 Operation and Run instructions
4.1.2 Keypad Indicators
Keypad is furnished with 6 indicators whose descriptions are as stated below
Table 4-2 Description of indicators
Indicator Designation Meaning
Hz Frequency indicator
ON: currently displayed parameter is run frequency
or the unit of current parameter is frequency
Flash: currently displayed parameter is set
frequency
A
Current indicator
ON: currently displayed parameter is current
V
Voltage indicator
ON: currently displayed parameter is voltage
Hz+A Run speed indicator
ON: currently displayed parameter is run speed
Flash: currently displayed parameter is set speed
A+V
Percentage indicator
ON: currently displayed parameter is percentage
All OFF
No unit
No unit
RUN Run status indicator
ON: Run
OFF: Stopped
Flash: Stopping
FWD Forward indicator
ON: If the drive in stop status, forward command
enabled. If the drive in run status, the drive is
running forward
Flash: Forward is switching to reverse
REV Reverse indicator
ON: If the drive in stop status, reverse command
enabled. If the drive in run status, the drive is
running reversely.
Flash: Reverse is switching to forward
- 38 -
