Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
1: Opposite direction allowed
Decade: integration selection
0:
Integral continued when frequency
attains upper/lower frequency
1: Integral stopped when frequency
attains upper/lower limit
F0-04
PID positive and negative
adjustment
0: Positive adjustment
1: Negative adjustment
0 ×
F0-05
Filtering time of PID setting
0.00s~60.00s
0.00s
△
F0-06
Filtering time of PID feedback
0.00s~60.00s
0.00s
△
F0-07
Filtering time of PID output
0.00s~60.00s
0.00s
△
F0-08
Proportional gain Kp1
0.0~100.0
50.0
△
F0-09
Integration time Ti1
0.001s
～
50.000s
0.500s
△
F0-10
Differential time Td1
0.0s~100.0s
0.0s
△
F0-11
Proportional gain Kp2
0.0~100.0
50.0
△
F0-12
Integration time Ti2
0.001s
～
50.000s
0.500s
△
F0-13
Differential time Td2
0.0s~100.0s
0.0s
△
F0-14
PID parameter switch
selection
0: No switch, determined by
parameters Kp1, Ti1 and Td1
1: Auto switch on the basis of input
offset
2: Switched by terminal
0 ×
F0-15
PID auto-switch Input offset
0.0%~100.0%
20.0%
△
F0-16
Sampling period T
0.006s
～
50.000s
0.008s
△
F0-17
PID offset limit
0.0%~100.0%
0.0%
△
F0-18
PID differential limit
0.0%~100.0%
0.5%
△
F0-19
PID initial value
0.0%~100.0%
0.0%
×
F0-20
Holding time of PID initial value
0.0s~3600.0s
0.0s
△
F0-21
PID feedback loss detection value
0.0%~100.0%
0.0%
△
F0-22
PID feedback loss detection time
0.0s~30.0s
1.0s
△
F0-23
Maximum frequency when opposite to
command run direction
0.00Hz~mximum frequency 50.00Hz △
F0-24
PID
computation option
0: No computation in stop status
1: Computation continued in stop
status
0 △
Group F1 Multi-step Frequency
F1-00
F
requency command source of
multi
-step 0
0: Digital setting F1-02
1: Digital setting b0-02 + keypad ∧/∨
adjustment
2: Digital setting b0-02 + terminal
0 ×
- 62 -
