Group b1 Start/Stop C ontrol
b1-00
Run command
Range: 0 - 2
Factory default: 0
This parameter sets run command source. Run commands include "start, stop, forward and
reverse", etc.
0: Keypad control
Control run command through RUN, STOP/RESET and MF keys on keypad (set
multifunction key MF to JOG by L0-00). Refer to Chapter 4 about the operation of keypad.
1: Terminal control
Control run command via DI terminals. Perform FORWARD and REVERSE by DI terminals.
The control mode are two-wire mode and three-wire mode selectable. See Group C0 for
details of designation and wiring regulation of DI terminals.
2: Communication control
Master device is able to control run command through built-in RS485 serial communication
interface of drive. Refer to parameters Group H0 and appendix for further information about
programming.
Run command from keypad, terminals and communication can be switched by terminals "run
command switched to keypad control", "run command switched to terminal control" and "run
command switched to communication control".
Multifunction key MF can be set to "run command sources shifted" key through parameter
L0-00. When MF key is pressed under this setting, run command will be shifted during keypad
control, terminal control and communication control circularly.
b1-01
Binding of run command
and frequency
command
Range: 000 - AAA
Factory default:
000
This parameter defines the bundled combination of three run command sources and frequency
command sources with the purpose of facilitating simultaneous switching.
For example: frequency command source AI (unit's place of b1-01 is set to 3) bundled with
keypad control, while the frequency command source X6/DI pulse input (ten's place of b1-01 is
set to 6) bundled with terminal control. In such a case, when run command is controlled by
keypad, frequency command source would be AI, while when run command is controlled via
terminals, frequency command source will be automatically switched to X6/DI pulse input.
