Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
H0-04 Communication time delay Range: 0ms - 1000ms
Factory default:
0ms
Sets response time delay of this drive to the master.
H0-05
Master/Slave option
Range: 0 - 2
Factory default: 0
0: PC controls the drive
PC as master controls the drive. This supports all communication protocols.
1: As master
This drive as master sends current running frequency data through RS-485 port. Data cannot
be received but sent, and the sending data is only running frequency.
2: As slave
Put the received data into b0-02 (digital setting of master frequency) or F0-01 (PID digital
setting) through communication. b0-02/F0-01 is selected by parameter H0-06. Other
communication data addresses are not supported. As slave, this drive can only receive the
data.
H0-06
Parameter store address
Range: 0 - 1
Factory default: 0
0: b0-02
1: F0-01
Enabled when H0-05 is set to 2. This parameter sets the store address of received data when it
works as slave.
H0-07
Proportional factor of received
frequency
Range: 0.0% - 100.0%
Factory default:
100.0%
Enabled when H0-05 is set to 2. Received data is multiplied by H0-07 and then put the result
into the address set by H0-06. This parameter setting is very useful when a master drive control
a number of slave drives and needs to allocate the frequency.
- 139 -
