Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
Group L Keys and Display of Keypad
Group L0 Keys of K eypad
0: Not locked
1: Full locked
2: Keys locked other than RUN, STOP/RESET
3: Keys locked other than STOP/RESET
4: Keys locked other than >>
Please refer to Chapter 4 for locking operation of keys.
0: STOP key valid only when under keypad control
1: STOP key valid under any run command source
L0-03
Frequency adjustment through
keys
∧ / ∨
Range: 0000 - 1111
Factory default:
Unit's place: option on stop
0: Clear on stop
Keys ∧ / ∨frequency adjustment step size is cleared at the stop of drive.
1: Holding on stop
Keys ∧ / ∨frequency adjustment step size is held at the stop of drive.
Decade: option on power loss
0: Clear on power loss
Keys ∧ / ∨ frequency adjustment step size is cleared at power loss.
1: Holding on power loss
Keys ∧ / ∨frequency adjustment step size is saved on power loss.
Hundreds place: integrating option
0: Integrating disabled
Adjustment step size is kept constant when frequency is adjusted by keys ∧ / ∨, and the
adjustment will be performed always with the step size set by L0-04.
1: Integrating enabled
When frequency is adjusted by keys ∧ / ∨, the initial step size is the set value of L0-04. With
the press increase of ∧ / ∨, adjustment step size shows cumulative integrating effect and will
increase gradually.
Thousands place: run direction
0: Run direction not allowed to change
1: Run direction allowed to change
- 140 -
