Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
 Unit's place: frequency command source bundled under keypad control
0: No binding
1: Digital setting (b0-02) + ∧ / ∨ adjustment on keypad
2: Digital setting (b0-02) + terminal UP/DOWN adjustment
3: Analogue input AI
4: Keypad potentiometer
7: Process PID output
9: Multi-step frequency
A: Communication input
Refer to parameter b0-01 for details regarding above-mentioned sources of frequency
command.
 Decade: frequency command source bundled under terminal control (same as unit's place)
 Hundreds place: frequency command source bundled under communication control (same
as unit's place)
 ATTENTION:
 Different run command sources can be bundled with the same frequency command
source.
 The priority of frequency command sources bundled with run command overrides
Group b0.
b1-02
Running direction
Range: 0 - 1
Factory default: 0
This parameter applies to run command controlled by keypad, and disabled under terminal and
communication control.
0: Forward
1: Reverse
b1-03
Reverse disabled
Range: 0 - 1
Factory default: 0
0: Reverse enabled
1: Reverse disabled
In some applications, reverse is likely to result in equipment damage. This parameter is used to
prevent reverse running
.
b1-04
Dead time of forward
and reverse
Range: 0.0s - 3600.0s
Factory default:
0.0s
The dead time with 0Hz output during the transition from forward to reverse, or from reverse to
forward is indicated by letter "t" in Fig. 6-9.
- 85 -
