Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
5: 1-7-1-
O format, ASCII
Hundreds place: connection type
0: D
irect cable connection (232/485)
1: MODEM (232)
Thousands place: storage
0: Not stored at power loss
1: Stored at power loss
H0-02
RS-485 communication address
0~247, 0 is broadcast address
1
×
H0-03
Time out detection
0.0s~1000.0s
0.0s
×
H0-04
Communication time delay
0ms~1000ms
0ms
×
H0-05
M
aster/Slave option
0: Independently used
1: As master
2: As slave
0 ×
H0-06
Parameter storage
address
0:b0-02
1:F0-01
0 ×
H0-07
Proportional
factor of received
frequency
0.0%~1000.0% 100.0% △
Group L Keys and Display of Keypad
Group L0 Keys of Keypad
L0-01
Key
s locked selection
0: Not locked
1: Full locked
2: Keys locked other than RUN,
STOP/RESET
3: Keys locked other than
STOP/RESET
4: Keys locked other than >>
0 △
L0-02
Function of STOP key
0: STOP key valid only when under
keypad control
1: STOP key valid under any run
command source
0 △
- 64 -
