Emotron VSB Series User Manual

Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
b1-10
Flying start current
0.0% - 200.0%
100%
△
B1-11
Flying start time
0.1s – 20.0s
2.0s
△
b1-13
Stop
method
0: Ramp to stop
1: Coast to stop
2: Ramp to stop + DC brake
0 ×
b1-14
Start frequency of DC brake stop
0.00Hz~upper limit frequency
0.00Hz
×
b1-15
Brake current
0.0%~100.0%
0.0%
△
b1-16
Brake time
0.00s~30.00s
0.00s
△
b1-17
O
verexcitation brake
0: Disabled
1: Enabled
1 ×
b1-18
D
ynamic brake
0: Disabled
1: Enabled
0 ×
b1-19
Dynamic brak
e threshold voltage
200V: 325V~375V, default: 375V
400V: 650V~750V, default: 720V
Model
defined
×
b1-20
Auto restart when power up again
after power loss
0: Disabled
1: Enabled
0 ×
b1-21
Waiting time
of auto restart when
power up again
0.0s~10.0s 0.0s △
Group b2 Accel/Decel Parameters
b2-00
Accel/Decel
time resolution
0: 0.01s
1: 0.1s
2: 1s
1 ×
b2-01
Accel time 1
0s~600.00s/6000.0s/60000s
6.0s
△
b2-02
Decel time 1
0s~600.00s/6000.0s/60000s
6.0s
△
b2-03
Accel time 2
0s~600.00s/6000.0s/60000s
6.0s
△
b2-04
Decel time 2
0s~600.00s/6000.0s/60000s
6.0s
△
b2-05
Accel time 3
0s~600.00s/6000.0s/60000s
6.0s
△
b2-06
Decel time 3
0s~600.00s/6000.0s/60000s
6.0s
△
b2-07
Accel time 4
0s~600.00s/6000.0s/60000s
6.0s
△
b2-08
Decel time 4
0s~600.00s/6000.0s/60000s
6.0s
△
b2-09
Decel time when emergency stop
enabled
0s~600.00s/6000.0s/60000s
6.0s △
b2-10
Jog Accel time
0s~600.00s/6000.0s/60000s
6.0s
△
b2-11
Jog Decel time
0s~600.00s/6000.0s/60000s
6.0s
△
b2-12
Accel
/Decele curve selection
0: Linear Accel/Decel
1: Broken-line Accel/Decel
2: S-curve Accel/Decel
0 ×
b2-13
Accel time switching frequency of
broken-line Accel/Decel
0.00Hz~upper limit frequency 0.00Hz △
b2-14
Decel time switching frequency of
0.00Hz~upper limit frequency
0.00Hz
△
- 51 -
