Emotron VSB Instruction Manual Chapter 3 Installation and wiring
3.4 Selection of Peripheral Devices
Table 3-1 S election of peripheral devices
Model Breaker（A） Contactor（A）
Brake unit
Power（W） Resistor（Ω）
VSU23-003-20CNB
16 10 70 ≥200
VSU23-005-20CNB
25 16 70 ≥200
VSU23-008-20CNB
32 25 260 ≥100
VSU23-011-20CNB
40 32 260 ≥75
VSU48-003-20CNB 16 10 300 ≥150
VSU48-004-20CNB
16 10 450 ≥100
VSU48-006-20CNB
16 10 600 ≥75
VSU48-009-20CNB
40 32 600 ≥75
* All models have inbuilt brake unit, and brake resistors should be sourced. Strictly conform to the requirement in the
form.
Failure to comply may result in equipment damage.
