Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
b0-00
Frequency command
pattern
Range: 0 - 4
Factory default:
0
0: Master frequency command
Output frequency of drive is determined by master frequency command source b0-01. Refer
to parameters b0-01 and b0-02 for further information.
1: Master & auxiliary computation result
Frequency command is the result of master & auxiliary computation. The master & auxiliary
computation relation is determined by b0-07. Main command is set by b0-01, while auxiliary
is set by b0-03.
2: Switch between master frequency command, and auxiliary frequency command
When b0-00 is set to 2, the switch between master frequency command, and master &
auxiliary computation result can be realized through digital input terminal "frequency
command switchover". When terminal "frequency command switchover" is invalid, command
frequency of the drive will be determined by b0-01. When terminal "frequency command
switchover" is valid, command frequency of the drive will be determined by b0-03 (Auxiliary
frequency command source).
3: Switch between master frequency command, and master & auxiliary computation result
When b0-00 is set to 3, command frequency will de determined by master frequency
command, or master & auxiliary computation result through digital input terminal "frequency
command switchover". When terminal "frequency command switchover" is invalid, command
frequency is determined by b0-01 (master frequency command source). When terminal
"frequency command switchover" is valid, command frequency is determined by master &
auxiliary computation result. The master & auxiliary computation relation is determined by
b0-07.
4: Switch between auxiliary frequency command, and master & auxiliary computation result
When b0-00 is set to 4, command frequency will de determined by auxiliary frequency
command, or master & auxiliary computation result through digital input terminal “frequency
command switchover”. When terminal "frequency command switchover" is invalid, command
frequency is determined by b0-03 (auxiliary frequency command source). When terminal
"frequency command switchover" is valid, command frequency is determined by master &
auxiliary computation result. The master & auxiliary computation relation is determined by
b0-07.
b0-01
Master frequency
command source
Range: 0 - 9
Factory default:
0
0: Digital setting (b0-02) + ∧ / ∨ adjustment on keypad
When the drive is powered up, the value of b0-02 is taken as the master frequency command
which can be adjusted through ∧ / ∨ keys on keypad no matter the drive is running or in
stop.
- 73 -
