Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
26: Accumulative running time
attained
C1-04
Y output time delay
0.0s~3600.0s
0.0s
△
C1-06
Relay output time delay
0.0s~3600.0s
0.0s
△
C1-08
Enabled
state of digital output
Unit's place: Y
0: Positive logic
1: Negative logic
Decade: Reserved
Hundreds place: control board relay
output (same as unit's place)
000 ×
C1-09
Detective
object of frequency
doubling technology
(FDT)
Unit's place: FDT1 detective object
0: Set value of speed (frequency
after Accel/Decel)
1: Detected speed value
Decade: FDT2 detective object
0: Set value of speed (frequency
after Accel/Decel)
1: Detected speed value
00 △
C1-10
FDT1 upper bound
0.00Hz~maximum frequency
50.00Hz
△
C1-11
FDT1 lower bound
0.00Hz~maximum frequency
49.00Hz
△
C1-12
FDT2 upper bound
0.00Hz~maximum frequency
25.00Hz
△
C1-13
FDT2 lower bound
0.00Hz~maximum frequency
24.00Hz
△
C1-14
Detection w
idth of frequency
attained
0.00Hz~maximum frequency 2.50Hz
△
C1-15
Zero current detection level
0.0%~50.0%
5.0%
△
C1-16
Zero current detection time
0.01s~50.00s
0.50s
△
Group C2 Analog Input
C2-00
A
nalog input curve selection
Unit's place: AI input curve
0: Curve 1 (2 points)
1: Curve 2 (4 points)
Decade: Potentiometer input curve
(same as unit's place)
00 ×
C2-01
Maximum input of curve 1
Minimum input of curve 1 ~ 110.0%
100.0%
×
C2-02
Corresponding s
et value of curve 1
maximum input
-100.0%~100.0% 100.0% ×
C2-03
Minimum input of curve 1
-110.0% ~ maximum input of curve 1
0.0%
×
C2-04
Corresponding s
et value of curve 1
minimum input
-100.0%~100.0% 0.0% ×
C2-05
C
urve 2 maximum input
Range: Inflection point A input of
curve 2~110.0%
100.0% ×
- 55 -
