Emotron VSB Instruction Manual Chapter 6 Specification of Parameters
F1-02
Multi-step frequency 0
Lower limit frequency -
upper limit frequency
Factory default:
0.00Hz
F1-03
Multi-step frequency 1
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-04
Multi-step frequency 2
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-05 Multi-step frequency 3
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-06 Multi-step frequency 4
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-07 Multi-step frequency 5
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-08 Multi-step frequency 6
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
F1-09 Multi-step frequency 7
Lower limit frequency -
upper limit frequency
Factory default:
0.00 Hz
At most 8 steps of multi-step frequency can be set by different status combinations of
"multi-step frequency terminals 1 - 4" of digital input, as shown in Table 6-7.
Table 6-7
Multi-step
terminal 4
Multi-step
terminal 3
Multi-step
terminal 2
Multi-step
terminal 1
Command frequency
OFF OFF OFF OFF
Multi-step frequency
0(F1-00)
OFF OFF OFF ON
Multi-step frequency
1(F1-01)
OFF OFF ON OFF
Multi-step frequency
2(F1-04)
OFF OFF ON ON
Multi-step frequency
3(F1-05)
OFF ON OFF OFF
Multi-step frequency
4(F1-06)
OFF ON OFF ON
Multi-step frequency
5(F1-07)
OFF ON ON OFF
Multi-step frequency
6(F1-08)
OFF ON ON ON
Multi-step frequency
7(F1-09)
- 137 -
