Page #71 background imageLoading...
Page #71 background image
Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param
Designation Range
Factory
default
Attr
L0-03
/ frequency adjustment
Unit's place: selection on stop
0: Clear on stop
1: Holding on stop
Decade: selection on power loss
0: Clear on power loss
1: Holding on power loss
Hundreds place: integral selection
0: Integral disabled
1: Integral enabled
Thousands place: run direction
0: Run direction not allowed to
change
1: Run direction allowed to change
0100
L0-04
Step size of
/frequency
adjustment
0.00Hz/s~10.00Hz/s 0.10 Hz/s
Group L1 LED Display Setting
L1-00
LED display
ed parameter settings
on running status
Setting of binary system:
0: Display disabled
1: Display enabled
Unit's place:
BIT0: Running frequency (Hz)
BIT1: Command
frequency (Hz)
BIT2: Bus voltage (V)
BIT3: Output current (A)
Decade:
BIT0: Output torque (%)
BIT1: Output power (kW)
BIT2: Output voltage (V)
BIT3: Motor speed (r/min)
Hundreds place:
BIT0: AI (V)
BIT1: Potentiometer (V)
BIT2: Input terminal status
BIT3: Output terminal status
Thousands place:
BIT0: PID setting (%)
BIT1: PID feedback (%)
BIT2: Reversed
BIT3: Reserved
Note: when this parameter is set to
0000, running frequency (Hz) would
000F
- 65 -
