Emotron VSB Series User Manual

Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
C2-06
C
orresponding set value of curve 2
maximum input
Range: -100.0%~100.0%
100.0% ×
C2-07
C
urve 2 inflection point A input
Curve 2 inflection point B input ~
curve 2 maximum input
0.0% ×
C2-08
Corresponding s
et value of curve 2
i
nflection point A input
Range: -100.0%~100.0%
0.0% ×
C2-09
C
urve 2 inflection point B input
Range: Curve 2 minimum input ~
curve 2 inflection point A input
0.0% ×
C2-10
Corresponding s
et value of curve 2
inflection point B input
Range: -100.0%~100.0%
0.0% ×
C2-11
Curve 2 m
inimum input
Range: -110.0%~ curve 2 inflection
point B input
0.0% ×
C2-12
C
orresponding set value of curve 2
minimum input
Range: -100.0%~100.0%
0.0% ×
C2-20
AI out of –limit detection time
0.00s – 100.00s
0.50s
△
C2-21
AI input filtering time
0.000s~10.000s
0.01s
△
C2-22
Potentiometer input filtering time
0.000s~10.000s
0.01s
△
Group C3 Analog Output
C3-00
AO output function
0: No output
1: Command frequency
2: Output frequency
3: Output current
4: Output torque
5: Output voltage
6: Output power
7: Bus voltage
9: Torque current
10: Magnetic flux current
11:AI
16:Communication input percentage
17: Output frequency before
compensation
2 △
C3-03
AO offset
-100.0%~100.0%
0.0%
×
C3-04
AO gain
-2.000~2.000
1.000
×
C3-05
AO filtering time
0.0s~10.0s
0.0s
△
Group C4 Automatic Correction of Analog Input
C4-00
Analog correct
ed channel
0: No correction
1:Correct AI
2:Correct potentiometer
0 ×
- 56 -
