Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
C4-01
Sampl
ing value of AI calibration
point 1
Range: 0.00V~10.00V
1.00V ■
C4-02
Input value of AI calibration point 1
Range: 0.00V~10.00V
1.00V
×
C4-03
Sampl
ing value of AI calibration
point 2
Range: 0.00V~10.00V
9.00V ■
C4-04
Input value of AI calibration point 2
Range: 0.00V~10.00V
9.00V
×
C4-05
Sampl
ing value of potentiometer
calibration point 1
Range: 0.00V~10.00V
1.00V ■
C4-06
Input value
of potentiometer
calibration point 1
Range: 0.00V~10.00V
1.00V ×
C4-07
Sampl
ing value of potentiometer
calibration point 2
Range: 0.00V~10.00V
9.00V ■
C4-08
Input value
of potentiometer
calibration point 2
Range: 0.00V~10.00V
9.00V ×
Group d Motor and Control Parameters
Group d0 Motor parameters
d0-00
Motor type
0: Ordinary motor
1: Variable frequency motor
0 ×
d0-01
Motor p
ower rating 0.4kW~6553.5kW
Model
defined
×
d0-02
Mo
tor rated voltage
200V: 0V～260V default: 220V
400V: 0V
～
480V default: 380V
Model
defined
×
d0-03
Motor r
ated current 0.0A~6553.5A
Model
defined
×
d0-04
Motor r
ated frequency 0.00Hz~maximum frequency 50.00Hz ×
d0-05
Motor pole number
1~80
4
×
d0-06
Motor r
ated speed 0~65535r/min
Model
defined
×
d0-07
Motor s
tator resistance R1 0.001Ω~65.535Ω
Model
defined
×
d0-08
Motor l
eakage inductance L1 0.1mH~6553.5mH
Model
defined
×
d0-09
Motor r
otor resistance R2 0.001Ω~65.535Ω
Model
defined
×
d0-10
Motor m
utual inductance L2 0.1mH~6553.5mH
Model
defined
×
d0-11
Motor n
o-load current 0.0A~6553.5A
Model
defined
×
d0-12
Motor flux weakening coeff 1
0.0000~1.0000
Model
×
- 57 -
