Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param
Designation Range
Factory
default
Attr
be displayed as default
L1-02
LED display
ed parameter settings
on stop status
Setting of binary system:
0: Display disabled
1: Display enabled
Unit's place:
BIT0: Command frequency (Hz)
BIT1: Bus voltage (V)
BIT2: Input terminal status
BIT3: Output terminal status
Decade:
BIT0: AI (V)
BIT1: Potentiometer (V)
BIT2: Reserved
BIT3: Reserved
Hundreds place:
BIT0: PID setting (%)
BIT1: PID feedback (%)
BIT2: Reserved
BIT3: Reserved
Thousands place: Reserved
Note: when this parameter is set to
0000, the set frequency would be
displayed as default (Hz)
0003
Group U Monitoring
Group U0 Status Monitoring
U0-00
Run frequency
0.00Hz~600.00Hz
0.00Hz
U0-01
Set frequency
0.00Hz~600.00Hz
0.00Hz
U0-02
Bus voltage
0V~65535V
0V
U0-03
Output voltage
0V~65535V
0V
U0-04
Output current
0.0A~6553.5A
0.0A
U0-05
Output torque
0.0%~300.0%
0.0%
U0-06
Output power
0.0%~300.0%
0.0%
U0-09
Master frequency setting
0.00Hz~600.00Hz
0.00Hz
U0-10
Auxiliary frequency setting
0.00Hz~600.00Hz
0.00Hz
