Emotron VSB Instruction Manual Chapter 5 List of Parameters
Param Designation Range
Factory
default
Attr
broken-line Accel/Decel
b2-15
Time of first segment of Accel
S-curve
0.00s~60.00s 0.20s
△
b2-16
T
ime of last segment of Accel
S-curve
0.00s~60.00s 0.20s
△
b2-17
Time of first segment of Decel
S-curve
0.00s~60.00s 0.20s
△
b2-18
T
ime of last segment of Decel
S-curve
0.00s~60.00s 0.20s
△
Group C Input and Output Terminals
Group C0 Digital Input
C0-00
Enabled condition of run command
terminals
when power up
0: Trigger edge detected + ON
detected
1: ON detected
0 ×
C0-01
F
unction of terminal X1
0: No function
1: JOG forward
2: JOG reverse
3: Run forward (FWD)
4: Run reverse (REV)
5: Three-wire control
6: Run suspended
7: External stop
8: Emergency stop
9: Stop command + DC brake
10: DC brake stop
11: Coast to stop
12: Terminal UP
13: Terminal DOWN
14: Clear UP/DOWN (including
keypad ∧/∨) adjustment
15: Multi-step frequency terminal 1
16: Multi-step frequency terminal 2
17: Multi-step frequency terminal 3
19: Accel/Decel time determinant 1
20: Accel/Decel time determinant 2
21: Accel/Decel disabled(ramp stop
not inclusive)
22: External fault input
23: Fault reset (RESET)
27: Run command switched to
keypad control
28: Run command switched to
3 ×
C0-02
F
unction of terminal X2 4 ×
C0-03
F
unction of terminal X3 1 ×
C0-04
F
unction of terminal X4 23 ×
C0-08
F
unction of terminal AI (Digital
enabled
)
0 ×
- 52 -
