Emotron VSB Instruction Manual Chapter 2 Product Information
Basic
functions
Start frequency
0.00 - 600.00Hz
Accel/Decel
time
0.00 - 60000s
Carrier
frequency
0.7kHz - 12kHz
Frequency
setting sources
Digital setting + keypad ∧ / ∨
Digital setting + terminal UP/DOWN
Potentiometer
Communication
Analogue setting (AI)
Motor started
methods
Started from starting frequency
DC braking and then started
Motor stopped
methods
Ramp to stop
Coast to stop
Ramp stop + DC brake
Basic
functions
Dynamic
braking
capacity
Brake unit threshold voltage:
400V input: 650V~750V
200V input: 325V～375V
service time: 0.0~100.0s
DC braking
capacity
DC braking start frequency: 0.00 - 600.00Hz
DC braking current: 0.0 - 100.0%
DC braking time: 0.0 - 30.00s
Input terminals
4 digital inputs
1 analog, current/voltage type selectable
Output
terminals
1 digital output
1 relay output
1 analog output, voltage/current output selectable; can
output signals such as setting frequency, or output
frequency, etc
- 12 -
