Emotron VSB Instruction Manual Chapter 4 Operation and Run instructions
Application parameter settings as below.
Table 4-6
Parameter
Designation
Set Value
Comment
b0-01
Master frequency reference source
8: Multi-step speed
Preset speeds
b0-08 Maximum frequency set value 50Hz *
b0-10 Minimum frequency set value 0Hz *
b1-00 Run command source 1: Terminal control Digital inputs
b2-01 Acceleration time 1 set value 6s *
b2-02 Deceleration time 1 set value 6s *
C0-01 Digital input X1 function 3: FWD Start button SB2
C0-02 Digital input X2 function 4: REW Reverse direcion
C0-03 Digital input X3 function 5: Multi-step Bit 0, speed selection
C0-04 Digital input X4 function 15:Multi-step Bit 1, speed selection
C0-19 FWD/REV terminal control mode 3: Two-wire mode 2
F1-00 Source for Preset frequency 0 0*: Digital setting F1-02
F1-01 Source for Preset frequency 1 0*: Digital setting F1-03
F1-02 Preset frequency 0 Set <Speed 0> Bit1=0, Bit0=0
F1-03 Preset frequency 1 Set <Speed 1> Bit1=0, Bit0=1
F1-04 Preset frequency 2 Set <Speed 2> Bit1=1, Bit0=0
F1-05 Preset frequency 3 Set <Speed 3> Bit1=1, Bit0=1
* = default value
- 46 -
